Description
60 V 40 Ah Swap Battery for Electric Motorcycles is a swappable LiFePO4 traction pack engineered for battery-exchange operations. This pack targets ride-hailing and delivery e-motorcycles that need more range per exchange than a light scooter pack can offer. It delivers 2.56 kWh of nominal energy at 64 V (60 V class) in a pack weighing approximately 22 kg, dimensioned to fit standard swap-dock bays so a rider can exchange a depleted unit for a charged one in seconds.
Cell & BMS Technology
The pack uses grade-A prismatic LiFePO4 cells in a 20S1P configuration. A smart BMS provides cell-level voltage monitoring, multi-point temperature sensing, active balancing, over-charge and over-discharge protection, short-circuit protection and current limiting. Communication runs over CAN / RS485 / UART, Bluetooth optional, allowing the swap cabinet and vehicle controller to read SOC, SOH, cycle count and fault history for billing, diagnostics and fleet management.
Safety & Cycle Life
LiFePO4 chemistry removes the thermal-runaway risk profile associated with nickel-based chemistries and delivers more than 6,000 cycles at 80% depth of discharge, which supports several years of service in high-utilisation fleets. The BMS keeps operation inside a -20 °C to +60 °C window, and the enclosure is sealed to IP67 against rain, dust and wash-down.
Charging
Standard charge voltage is 73 V with a maximum continuous charge current of 40 A, giving a full charge in approximately 2 hours from empty. The BMS accepts CC-CV charging from swap-station chargers and supports parallel rack charging. Alternative fast-charge profiles can be supplied on request.
Mechanical & Enclosure
The pack is housed in a welded aluminium case with powder-coated finish, an integrated carry handle and a latch and guide-rail interface. Overall dimensions are 300 × 180 × 200 mm. A reinforced, vibration-tested variant is available for two- and three-wheelers operating on unpaved roads.
Typical Use Cases
Used by e-motorcycle ride-hailing platforms, courier fleets and intercity delivery operators where a 2.56 kWh pack covers a full working shift between exchanges.
Customisation
Voltage, capacity, case dimensions, connector type, communication protocol and branding (labels, silk-screen and case colour) can all be customised for OEM and fleet programmes. Customisation on standard shells requires no new tooling; new tooling is quoted separately. Larger capacities than the standard range are available on a project basis.
Every unit is 100% capacity-tested and balance-tested before shipment. Compliance target standards: UN38.3, IEC 62619, CE and RoHS. Warranty: 3–5 years, depending on model.
| Minimum order | 20 units per model for a production order. Single units are available as paid evaluation samples, credited against your first production order. |
| Lead time | 25 days after the deposit is received for a standard batch. Tooling, custom BMS or project-specific capacity is scheduled separately and confirmed on the quotation. |
| Payment | T/T: 30% deposit with the order, balance against the bill of lading copy. |
| Shipment | Tell us the destination port or door. The quotation states the Incoterm and the freight option we are quoting, so the delivered cost is comparable across suppliers. |
| Packing | Packed to the packing instruction applying to UN3480 or UN3481, terminals protected, lithium battery mark and hazard label applied, pallets strapped and shrink-wrapped. |
| Documents with the goods | Packing list, commercial invoice, MSDS, UN38.3 test summary and report, shipper’s declaration for dangerous goods, and the bill of lading or air waybill. |
| Per unit | Datasheet for your model and the end-of-line test record for that serial number. |
| Warranty | 3–5 years, depending on model, written into the contract. |
| HS classification | Lithium-ion accumulators, heading 8507.60. The national tariff line and duty rate are confirmed against your destination before the order is placed. |
Packing and shipping
| Packing | Packed to the packing instruction applying to UN3480 or UN3481, terminals protected, lithium battery mark and hazard label applied, pallets strapped and shrink-wrapped. |
|---|
| Documents with the goods | Packing list, commercial invoice, MSDS, UN38.3 test summary and report, shipper’s declaration for dangerous goods, and the bill of lading or air waybill. |
|---|
| HS classification | Lithium-ion accumulators, heading 8507.60. The national tariff line and duty rate are confirmed against your destination before the order is placed. |
|---|
These three rows come from the sitewide commercial terms. All nine are on the Ordering and Support tab.
Download: Packing and shipping document checklist (PDF, 4 pages) · BMS protocol mapping note (PDF, 3 pages)
Typical lead time: 25 days after deposit · MOQ 20 units per model (single units available as paid evaluation samples, credited against your first production order) · Payment by T/T · Port of loading confirmed at quotation.
Other models on the same voltage platform
Models on one platform differ in capacity, BMS and enclosure – fitment follows the vehicle and the duty cycle; capacity, enclosure and connectors can be re-rated per project.
Selection matrix: the models of this line side by side (vehicle or load, voltage platform and capacity, current and thermal design, BMS and communication)
