Solar canopy over a commercial parking area

100kWh / 50kW Commercial & Industrial Battery Cabinet

Model YD-CI-100

Chemistry: LiFePO4 (LFP)
Nominal voltage: 51.2V DC nominal (16S)
Nominal energy: 100 kWh

Full specification sheet available with quotation

Wholesale & Project Pricing

Pricing is quotation-based. Send us your application, target market and annual volume — our engineering team replies with a technical proposal and price list within 48 hours.

Sample orders and trial batches supported
OEM/ODM customisation: cell, BMS, enclosure, packaging
UN38.3 / IEC 62619 export documentation provided

Request a Quotation

100 kWh / 50 kW air-cooled LiFePO4 C&I battery cabinet with 51.2V DC system, EMS integration and fire detection.

SKU: YD-CI-100

Category: Commercial & Industrial Energy Storage

Description

100 kWh / 50kW Commercial & Industrial Battery Cabinet is a 100 kWh lithium iron phosphate energy storage platform rated 50 kW for commercial and industrial applications. The 100 kWh cabinet is the smallest C&I platform in the range, intended for single-building deployments where site space and transformer capacity are limited. It is configured for grid-tied, behind-the-meter or hybrid operation.

Cells, Modules & BMS

The system is built from 280 Ah prismatic LiFePO4 cells in modules with a three-level (BMU / BCU / BAU) BMS architecture. Protection covers cell and module over-voltage, under-voltage, over-current, over-temperature, insulation fault and short circuit. Communication uses CAN / RS485 / Ethernet (Modbus TCP) for EMS, SCADA and cloud platform integration.

Thermal Management & Safety

Forced-air cooling with temperature-controlled fans maintains cell temperature uniformity across the cabinet. Multi-level fire protection is provided by aerosol suppression with smoke and temperature detection. The enclosure is rated IP54.

Cycle Life & Performance

Cells are specified for more than 6,000 cycles at 80% depth of discharge, with a usable SOC window of 5% – 95% and round-trip efficiency of 88% – 90% (DC round-trip, 0.5C). Modules can be replaced individually, limiting downtime and extending the cabinet’s economic life. Ambient operating range is -20 °C to +60 °C, with derating above 45C where required.

Charging & Grid Interface

DC nominal voltage is 51.2 V (16S) with a maximum continuous charge and discharge rate of 0.5C. The cabinet is supplied as a battery-only DC system and is paired with an external 50 kW PCS or a DC-coupled PV inverter. Operating modes include peak shaving, demand charge management, solar self-consumption and diesel generator support, scheduled through the EMS.

Mechanical & Installation

The unit is supplied as a single outdoor-rated cabinet measuring 1200 × 1000 × 2200 mm. The cabinet is pad-mounted with base cable entry and requires a level concrete foundation and a dedicated earthing point. Commissioning follows the supplied installation manual, with remote support available.

Deployment Scenarios

Applied to factories with 200-500 kW peak demand, cold storage and commercial buildings, telecom sites, and small mini-grids where the target is daily peak shaving or two to four hours of backup.

Customisation

Capacity, PCS rating, AC or DC coupling, protocol mapping and branding can be specified per project, and cabinet or container layouts can be adapted to site constraints. Larger capacities than the standard range are available on a project basis.

Factory battery module range

Storage systems are built from the following battery modules, with the system capacity configured per project:

Model	Chemistry	Nominal voltage	Nominal capacity
YD-48-100	LiFePO4	51.2 V	100 Ah
YD-48-200	LiFePO4	51.2 V	200 Ah
YD-48-280	LiFePO4	51.2 V	280 Ah
YD-48-314	LiFePO4	51.2 V	314 Ah
YD-48-942	LiFePO4	51.2 V	942 Ah

Other models are customised: storage cabinets from 5–200 kWh, and commercial and industrial storage from 200–5000 kWh.

Commercial and industrial storage is delivered as a complete system: battery system, battery management system, conversion system, thermal management system and fire protection system.

Each system is factory-tested for capacity, insulation, communication and protection functions. Compliance target standards: UN38.3, IEC 62619, IEC 62933, CE and RoHS. Warranty: 5 years, extendable to 8 years.

See how these packs are built → Factory & production

Typical Applications

Factories and industrial parks
Commercial buildings and hotels
Telecom sites and data centres
Mini-grids and microgrid projects
Diesel generator hybrid retrofits
Solar-plus-storage IPP projects

Packing and shipping

Packing	Packed to the packing instruction applying to UN3480 or UN3481, terminals protected, lithium battery mark and hazard label applied, pallets strapped and shrink-wrapped.
Documents with the goods	Packing list, commercial invoice, MSDS, UN38.3 test summary and report, shipper’s declaration for dangerous goods, and the bill of lading or air waybill.
HS classification	Lithium-ion accumulators, heading 8507.60. The national tariff line and duty rate are confirmed against your destination before the order is placed.

These three rows come from the sitewide commercial terms. All nine are on the Ordering and Support tab.

Download: Packing and shipping document checklist (PDF, 4 pages) · BMS protocol mapping note (PDF, 3 pages)

Typical lead time: 25 days after deposit · MOQ 20 units per model (single units available as paid evaluation samples, credited against your first production order) · Payment by T/T · Port of loading confirmed at quotation.

Selection matrix: the models of this line side by side (vehicle or load, voltage platform and capacity, current and thermal design, BMS and communication)

Need samples or technical documentation? Submit an inquiry below or contact our sales team directly.

Inquiry

Get a quotation for this product

Send the voltage platform, capacity, quantity and destination port, and we return the model, the unit price and the delivery date. Drawings or a sample pack help us confirm fitment.

This form is pre-filled with: YD-CI-100 — 100kWh / 50kW Commercial & Industrial Battery Cabinet (you can edit it in the "Product of interest" field)

Samples and documents: paid evaluation samples (credited against your first production order) · datasheet · packing and shipping document checklist · BMS protocol note — open the document centre

FAQ

Buyer FAQ

These answers match the sitewide terms and the quality page. Where a quotation differs, the quotation governs.

What is the minimum order quantity?

MOQ is 20 units per model. Single units are available as paid evaluation samples, and that cost is credited against your first production order.

What is the lead time?

Standard configurations ship 25 days after the deposit clears. Custom ratings, custom enclosures or multi-model orders carry the delivery date written into the quotation.

How do I pay?

Payment is by T/T. The deposit and balance proportions are written into the quotation before anything is produced.

Which standards and certificates apply?

Target standards are UN38.3, IEC 62619, CE and RoHS. LVD / EMC conformity is held under UDEM certificate M.2026.206.C143410, valid until 2031-06-29 and covering YD-24-314, YD-48-314 and YD-80-340. The certificate status that applies to your model is confirmed in writing with the quotation.

Certification table on the quality page

What documents ship with the goods?

Packing list, invoice, MSDS, UN38.3 summary report, dangerous goods declaration and the bill of lading, plus the datasheet and the factory inspection record for each unit. Packaging follows UN3480 / UN3481 and HS code 8507.60 applies. The port of loading is confirmed at quotation.

How long is the warranty?

Warranty is 3 to 5 years depending on the model and the duty cycle; energy storage models can be extended to 8 years. The term that applies is written into the quotation.

Where do the cells come from?

Cells are purchased directly from EVE Energy, Gotion High-tech and CALB. We state the purchase fact only, and we do not rank or recommend any supplier.

Can the battery be customised?

Voltage platform, capacity, enclosure and connectors can be re-rated per project, and the final configuration is written into the quotation. Drawings or a sample pack help us confirm fitment before tooling.

Minimum order	20 units per model for a production order. Single units are available as paid evaluation samples, credited against your first production order.
Lead time	25 days after the deposit is received for a standard batch. Tooling, custom BMS or project-specific capacity is scheduled separately and confirmed on the quotation.
Payment	T/T: 30% deposit with the order, balance against the bill of lading copy.
Shipment	Tell us the destination port or door. The quotation states the Incoterm and the freight option we are quoting, so the delivered cost is comparable across suppliers.
Packing	Packed to the packing instruction applying to UN3480 or UN3481, terminals protected, lithium battery mark and hazard label applied, pallets strapped and shrink-wrapped.
Documents with the goods	Packing list, commercial invoice, MSDS, UN38.3 test summary and report, shipper’s declaration for dangerous goods, and the bill of lading or air waybill.
Per unit	Datasheet for your model and the end-of-line test record for that serial number.
Warranty	3–5 years, depending on model, written into the contract.
HS classification	Lithium-ion accumulators, heading 8507.60. The national tariff line and duty rate are confirmed against your destination before the order is placed.
