100Ah 方形磷酸铁锂电芯 / 100Ah Prismatic LiFePO4 Cell

100Ah Prismatic LiFePO4 Cell

Model YD-CELL-100

Chemistry: LiFePO4 (LFP)
Nominal voltage: 3.2V
Nominal capacity: 100Ah
Nominal energy: 320 Wh

Full specification sheet available with quotation

Wholesale & Project Pricing

Pricing is quotation-based. Send us your application, target market and annual volume — our engineering team replies with a technical proposal and price list within 48 hours.

Sample orders and trial batches supported
OEM/ODM customisation: cell, BMS, enclosure, packaging
UN38.3 / IEC 62619 export documentation provided

Request a Quotation

100Ah prismatic LiFePO4 cell, 320 Wh, capacity and IR graded, over 6,000 cycles at 80% DoD.

SKU: YD-CELL-100

Category: LiFePO4 Cells & Custom Packs

Description

100 Ah Prismatic LiFePO4 Cell is a prismatic lithium iron phosphate cell for pack assembly, energy storage and industrial battery projects. The 100 Ah cell is the standard building block for 12 V to 48 V packs, portable storage and modular rack systems where weight per unit matters. Cells are purchased direct from major Chinese cell makers including EVE Energy, Gotion High-tech and CALB, then capacity-graded and resistance-matched in-house before packing. Each cell delivers 100 Ah at 3.2 V nominal, equivalent to 320 Wh, in the standard 174 × 72 × 207 mm prismatic format.

Cell Design & Construction

The cell uses a LiFePO4 cathode with a graphite anode, ceramic-coated separator and aluminium prismatic shell. A laser-welded safety vent releases internal pressure under abuse conditions, and the welded double-terminal design supports busbar bolting or laser welding in pack assembly. Cells are produced to a consistent winding and stacking process, so dimensional tolerance and terminal position are repeatable across batches.

Cycle Life & Safety

The chemistry delivers more than 6,000 cycles at 80% depth of discharge at 25C, with capacity retention specified against standard charge and discharge rates. LiFePO4 does not exhibit the thermal-runaway propagation behaviour of nickel-based chemistries, and the cell passes over-charge, over-discharge, nail penetration, crush and thermal abuse tests as part of type-testing programmes. Cells operate between -20 °C and +60 °C.

Charging & Discharge

Standard charge current is 0.5C (50 A) with a charge cut-off of 3.65 V, and continuous discharge is rated at 1C (100 A) to a 2.5 V cut-off. Pulse discharge capability is higher and can be specified for traction and start-assist applications. Cells are supplied at approximately 30% state of charge for safe transport.

Quality Control & Traceability

Every cell is capacity-graded, internal-resistance graded and self-discharge (K-value) screened before packing. Grade A cells are supplied with matched capacity, resistance and voltage within each delivery lot, and each cell carries a laser-etched batch code for traceability. Test data for capacity, resistance and OCV can be provided with each shipment.

Applications

Used for 12 V and 48 V lithium packs, home storage modules, telecom and UPS banks, marine and RV batteries, golf carts and light industrial equipment.

Matching & Customisation

Cells can be supplied as matched sets for series and parallel assembly, with busbars, terminal bolts, insulation paper and cell holders available as accessories. OEM and ODM pack programmes are supported where the customer requires finished packs rather than bare cells, and sample cells are available for qualification testing before volume orders. Other cell capacities and pack configurations are available on a project basis.

Compliance target standards: UN38.3, IEC 62619, CE and RoHS, with MSDS and transport documentation supplied for each shipment. Warranty: 3 years.

Video from the production line

Key Features

100Ah prismatic LiFePO4 cell, 320 Wh per cell
Capacity, internal resistance and K-value graded before packing
More than 6,000 cycles at 80% DoD at 25C
Energy density of approximately 150 Wh/kg
Laser-etched batch code for full traceability
Test data supplied with each shipment
Compact format for 12V to 48V pack builds and modular rack systems

Typical Applications

Solar and residential energy storage packs
Telecom and UPS backup systems
Electric two- and three-wheeler packs
Marine, RV and golf cart batteries
Industrial equipment and floor machines
Custom pack assembly programmes

Packing and shipping

Packing	Packed to the packing instruction applying to UN3480 or UN3481, terminals protected, lithium battery mark and hazard label applied, pallets strapped and shrink-wrapped.
Documents with the goods	Packing list, commercial invoice, MSDS, UN38.3 test summary and report, shipper’s declaration for dangerous goods, and the bill of lading or air waybill.
HS classification	Lithium-ion accumulators, heading 8507.60. The national tariff line and duty rate are confirmed against your destination before the order is placed.

These three rows come from the sitewide commercial terms. All nine are on the Ordering and Support tab.

Download: Packing and shipping document checklist (PDF, 4 pages) · BMS protocol mapping note (PDF, 3 pages)

Typical lead time: 25 days after deposit · MOQ 20 units per model (single units available as paid evaluation samples, credited against your first production order) · Payment by T/T · Port of loading confirmed at quotation.

Selection matrix: the models of this line side by side (vehicle or load, voltage platform and capacity, current and thermal design, BMS and communication)

Need samples or technical documentation? Submit an inquiry below or contact our sales team directly.

Inquiry

Get a quotation for this product

Send the voltage platform, capacity, quantity and destination port, and we return the model, the unit price and the delivery date. Drawings or a sample pack help us confirm fitment.

This form is pre-filled with: YD-CELL-100 — 100Ah Prismatic LiFePO4 Cell (you can edit it in the "Product of interest" field)

Samples and documents: paid evaluation samples (credited against your first production order) · datasheet · packing and shipping document checklist · BMS protocol note — open the document centre

FAQ

Buyer FAQ

These answers match the sitewide terms and the quality page. Where a quotation differs, the quotation governs.

What is the minimum order quantity?

MOQ is 20 units per model. Single units are available as paid evaluation samples, and that cost is credited against your first production order.

What is the lead time?

Standard configurations ship 25 days after the deposit clears. Custom ratings, custom enclosures or multi-model orders carry the delivery date written into the quotation.

How do I pay?

Payment is by T/T. The deposit and balance proportions are written into the quotation before anything is produced.

Which standards and certificates apply?

Target standards are UN38.3, IEC 62619, CE and RoHS. LVD / EMC conformity is held under UDEM certificate M.2026.206.C143410, valid until 2031-06-29 and covering YD-24-314, YD-48-314 and YD-80-340. The certificate status that applies to your model is confirmed in writing with the quotation.

Certification table on the quality page

What documents ship with the goods?

Packing list, invoice, MSDS, UN38.3 summary report, dangerous goods declaration and the bill of lading, plus the datasheet and the factory inspection record for each unit. Packaging follows UN3480 / UN3481 and HS code 8507.60 applies. The port of loading is confirmed at quotation.

How long is the warranty?

Warranty is 3 to 5 years depending on the model and the duty cycle; energy storage models can be extended to 8 years. The term that applies is written into the quotation.

Where do the cells come from?

Cells are purchased directly from EVE Energy, Gotion High-tech and CALB. We state the purchase fact only, and we do not rank or recommend any supplier.

Can the battery be customised?

Voltage platform, capacity, enclosure and connectors can be re-rated per project, and the final configuration is written into the quotation. Drawings or a sample pack help us confirm fitment before tooling.

Minimum order	20 units per model for a production order. Single units are available as paid evaluation samples, credited against your first production order.
Lead time	25 days after the deposit is received for a standard batch. Tooling, custom BMS or project-specific capacity is scheduled separately and confirmed on the quotation.
Payment	T/T: 30% deposit with the order, balance against the bill of lading copy.
Shipment	Tell us the destination port or door. The quotation states the Incoterm and the freight option we are quoting, so the delivered cost is comparable across suppliers.
Packing	Packed to the packing instruction applying to UN3480 or UN3481, terminals protected, lithium battery mark and hazard label applied, pallets strapped and shrink-wrapped.
Documents with the goods	Packing list, commercial invoice, MSDS, UN38.3 test summary and report, shipper’s declaration for dangerous goods, and the bill of lading or air waybill.
Per unit	Datasheet for your model and the end-of-line test record for that serial number.
Warranty	3–5 years, depending on model, written into the contract.
HS classification	Lithium-ion accumulators, heading 8507.60. The national tariff line and duty rate are confirmed against your destination before the order is placed.
